TP4056 Top Power ASIC Li-Ion Battery Charger Data Sheet

Download PDF datasheet for Top Power ASIC TP4056 Standalone Linear Li-Ion Battery Charger with Thermal Regulation (EN) 3 pages 2008 zip

SKU: TOPPOWERASICCORPTP4056DS2008 Category: Brand:

Description

This PDF data sheet is for the Top Power ASIC TP4056 Standalone Linear Li-Ion Battery Charger with Thermal Regulation.

Top Power ASIC TP4056 Standalone Linear Li-Ion Battery Charger with Thermal Regulation

The TP4056 is a complete constant-current/constant-voltage linear charger for single cell lithium-ion batteries. Its SOP package and low external component count make the TP4056 ideally suited for portable applications. Furthermore, the TP4056 can work within USB and wall adapter.

(PDF) DATASHEET in English (EN) language.

CONTENTS:

FEATURES

PACKAGE/ORDER INFORMATION

ABSOLUTE MAXIMUM RATINGS

APPLICATIONS

TP4056 PINOUT

Fig. Complete Charge Cycle (1000mAh Battery)

ELECTRICAL CHARACTERISTICS

TYPICAL APPLICATIONS

This data sheet provides all the information (according to the table of contents) from Top Power ASIC about the TP4056 Standalone Linear Li-Ion Battery Charger with Thermal Regulation. You can download and save it for offline use, including viewing it on your device or printing it for your convenience if you prefer a paper version.
