Sanyo STK412-040 Audio Power Amplifier Data Sheet

Description

This PDF datasheet is for the Sanyo STK412-040 audio power amplifier IC.

About the Item

Sanyo STK412-040 120W+120W Two-Channel Shift Power Supply Audio Power Amplifier IC

The STK412-000 series are class H audio power amplifier hybrid ICs that feature a built-in Shift power supply circuit. These ICs provide high efficiency audio power amplification by controlling (switching) the supply voltage supplied to the power transistors according to the detected level of the input audio signal.

FEATURES
– Pin compatible IC series that covers power ratings from 50 W x 2 channels to 180 W x 2 channels at 0.7 or 0.8% THD, 20 Hz to 20 kHz. This allows the use of a common PCB for all output classes.
– The pin arrangement is also unified with that of the three-channel STK413-000 series. This means that PCBs designed for three-channel models can also be used for two-channel models.
– Miniature package
– Allowable load shorted time: 0.3 s

Document(s) available

(PDF) DATASHEET

Available languages

ENGLISH (EN)

SUMMARY OF CONTENTS

– Package Dimensions. Case Outline.
– Series Organization
– Specifications
– Maximum Ratings
– Operating Characteristics
– Specified Transformer Power Supply (MG-250 equivalent)
– Specified Transformer Power Supply (MG-200 equivalent)
– Internal Equivalent Circuit
– Sample Application Circuit

Why download the Datasheet?

This datasheet provides all the information from SANYO about the STK412-040 audio power amplifier IC, as detailed in the table of contents. Reading it completely will address most questions you might have. You can download and save it for offline use, including viewing it on your device or printing it for your convenience if you prefer a paper version.
