Sanyo STK405-030 Audio Power Amplifier Data Sheet

Description

This PDF datasheet is for the Sanyo STK405-030 audio power amplifier IC.

About the Item

Sanyo STK405-030 20W+20W Two-channel AF Power Amplifier (Split Power Supply)

The STK405-030, a member of the STK405-000 series, is a low-cost, 2-channel audio power amplifier hybrid IC that is ideal for a wide range of stereo sets. It has dedicated 6 Ohm output drive, in contrast with the STK401-000 series which supports 6 Ohm / 3 Ohm output drive.

FEATURES
– Class B amplifiers
– Output load impedance RL=6W support
– EIAJ-output compatible (f=1kHz, THD=10%)
– Low supply switching shock noise
– Pin assignment grouped into individual blocks of inputs, outputs and supply lines to minimize the adverse effects of pattern layout on operating characteristics
– External boostrap circuit not necessary
– Standby operation possible using external circuit
– Voltage gain VG=26dB for easy gain distribution within the set
– Member of 10W/ch to 80W/ch pin-compatible series

Document(s) available

(PDF) DATASHEET

Available languages

ENGLISH (EN)

SUMMARY OF CONTENTS

– Series Organization
– Package Dimensions. Case Outline.
– Specifications
– Maximum Ratings
– Operating Characteristics
– Specified Transformer Supply (RP-22 or Equivalent)
– Block Diagram
– Test Circuit
– Sample Application Circuit (Standby Mode Supported)
– Heatsink Design Considerations

Why download the Datasheet?

This datasheet provides all the information from SANYO about the STK405-030 audio power amplifier IC, as detailed in the table of contents. Reading it completely will address most questions you might have. You can download and save it for offline use, including viewing it on your device or printing it for your convenience if you prefer a paper version.

How to download the Datasheet?

Download it by clicking the button below
