A-9030 Onkyo Integrated Amplifier Instruction Manual

Description

These PDF service and instruction manuals are for the Onkyo A-9030 integrated amplifier.

About the Item

Onkyo A-9030 65W+65W 8 Ohm Integrated Stereo Amplifier

Please read this manual thoroughly before making connections and plugging in the unit.
Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new Integrated Amplifier.
Please retain this manual for future reference.

Document(s) available

(PDF) INSTRUCTION MANUAL

Available languages

ENGLISH (EN) | DEUTSCH (DE) | ITALIANO (IT) | NEDERLANDS (NL) | SVENSKA (SV)

SUMMARY OF CONTENTS

INTRODUCTION
– Important Safety Instructions
– Precautions
– Supplied Accessories
– Features
– Before Using the Integrated Amplifier
– Installing the Batteries
– Using the Remote Controller
– Installing the Integrated Amplifier
– Getting to Know the Integrated Amplifier. Front Panel. Rear Panel. Remote Controller.

CONNECTIONS
– Connections
– Connecting Your Speakers
– Cable and Jacks
– Connecting the Power Cord
– Connecting a CD Player
– Connecting a Tuner
– Connecting an Onkyo Dock
– Connecting Onkyo u Components
– Connecting a Turntable
– Connecting a Cassette Tape Deck
– Connecting a Recording Component
– Connecting a Subwoofer With Built-In Power Amplifier
– Using the Integrated Amplifier as a Preamplifier

TURNING ON & BASIC OPERATIONS
– Basic Operations
– Turning On/Off the Integrated Amplifier
– Selecting Speakers A and Speakers B
– Adjusting the Volume
– Selecting the Input Source
– Using the Direct Function
– Using the PHASE MACHING BASS Function
– Adjusting the Bass, Treble and Balance
– Muting the Sound
– Using Headphones

ADVANCED OPERATIONS
– Custom Setup
– Setting the Auto Standby Function
– Setting the speaker impedance

OTHERS
– Troubleshooting
– Specifications

(PDF) SERVICE MANUAL for ONKYO A-9030 A-9050 (B)/(S)

SUMMARY OF CONTENTS

102 pages Ref. No. 4412 092012 (EN|JA)

– Service Procedure
– Operation Check
– Exploded Views
– Schematic Diagrams
– Exploded View Parts List
– PC Board Parts List
