BigBlue Cellpowa 2500 Portable Power Station User Manual

Download PDF user manual for BigBlue Cellpowa 2500 Portable Power Station 2500W (peak 5000W) 1843.2Wh LiFePO4 (EN|DE|ES|FR|IT|JA) 23 pages 2023 zip

SKU: BIGBLUECELLPOWA2500UM Category: Brand:

Description

This PDF user manual is for the BigBlue Cellpowa 2500 Portable Power Station.

BigBlue Cellpowa 2500 Portable Power Station | 2500W (peak 5000W) 1843.2Wh LiFePO4

The product is intended to provide electricity for your electrical or electronic appliances in the event of a power outage or during a trip. Equipped with DC output, USB output and AC output, the product can supply electricity to devices such as mobile phones, tablets, notebooks as well as lighting and automobile devices. The product has a built-in LifePO4 battery, which is the safest and most reliable.
Comes with the new Bullet-D fast charging technology, the AC input lets you seamlessly and quickly recharge your Cellpowa 2500 from the grid, reaching 80% capacity in 1.5 hours.
UPS function: Cellpowa 2500 can automatically detect the grid and power up your devices within 10ms.

Read all instructions carefully before using this product. This manual is intended to assist you in using the product.

(PDF) USER MANUAL in English (EN), German (DE), Spanish (ES), French (FR), Italian (IT) and Japanese (JA) languages.

CONTENTS:

1. Disclaimer
2. Introduction
3. Safety Instructions
4. Technical Data
5. Product Overview
5.1 Connectors
5.2 Screen
5.2.1 Primary User Interface
5.2.2 Secondary User Interface
6. APP Guide
6.1 Registration and Login
6.2 Connect to Cellpowa 2500
6.3 APP Operation
6.4 APP Download
7. Operation
7.1 Output Mode
7.1.1 AC Output
7.1.2 DC, USB-A and USB-C Outputs
7.2 Input Modes
7.2.1 AC Input
7.2.2 Solar Recharging
7.2.3 Car Recharging
7.3 GPS Positioning
8. Battery Instructions
9. Recycling
10. Warranty
11. Contact Information
12. Certifications

13. FAQ:

Q: Can I use third-party solar panels to recharge this product?
A: Yes. Any solar panel with an XT60 female connector as well as an output of 12-65V/22.5A (max. 25A) and max. 1200W can be used to recharge the Cellpowa 2500 power station.

Q: Does the Cellpowa 2500 power station use a pure sine wave inverter?
A: Yes. all BigBlue portable power stations use pure sine wave inverters, which won’t damage the product components when in use.

Q: Why should over-discharge and overcharge be avoided?
A: Overcharge and over-discharge will shorten the battery’s life span. It is recommended to keep the battery charge between 20% and 80%.

Q: Why can’t I use the UPS function?
A: Enable that the AC switch is turned on before using the UPS function.

Q: Why doesn’t GPS work indoors?
A: In most indoor cases, GPS signals will be blocked or reflected by obstructions. So, it is recommended to use the GPS positioning in an open air.

Q: What is the material of the shell of Cellpowa 2500? Is it environmentally friendly?
A: The shell of CP2500 is made of 94V-0 rated flame retardant high-strength ABS+PC. The material is environmentally friendly.

Q: What are the advantages of lithium iron phosphate (LiFePO4) batteries?
A: Lithium iron phosphate batteries use LiFePO4 as the cathode material, offering the advantages such as superior safety performance, longer life cycle and lower self-discharge rate.

This user manual provides all the information (according to the table of contents) from BigBlue about the Cellpowa 2500 Portable Power Station, including answers to the questions listed above. You can download and save it for offline use, including viewing it on your device or printing it for your convenience if you prefer a paper version.
